Desticker Assembly · Thomas Thomas Pre-Cleaner / Dump Cart
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | P300-100 | FRONT CONTAINMENT RUBBER | 1 |
| 1 | P305-000A | DRIVE SHAFT ASSEMBLY | 1 |
| 2 | P305-000 | DRIVE SHAFT ASSEMBLY | 1 |
| 2 | P306-000 | TAKE-UP SHAFT ASSEMBLY 1 11 P306-001A TAKE UP BEARING MOUNT | |
| 3 | P306-000 | TAKE UP SHAFT ASSEMBLY | 1 |
| 3 | E01-555-001 | TORQUE ARM 1 12 - 8 " LOCK WASHER | 12 |
| 4 | P307-000 | RETURN ROLLER ASSEMBLY | 6 |
| 4 | HYDM-TBO295 | DRIVE MOTOR 1 13 - 8 " FLAT WASHER | 8 |
| 5 | P308-000 | DS SPLASH PAN ASSEMBLY | 1 |
| 5 | CPL-16-16 | 1" X 1" SPLIT COLLAR 1 14 - 8 " HEX NUT | 8 |
| 6 | P309-000 | PS SPLASH PAN ASSEMBLY | 1 |
| 6 | BR-PB16 | 1" PILLOW BLOCK BEARING (HCAK205-16) 2 15 - 8 " x 1" HEX BOLT | 4 |
| 7 | P310-000 | BUMP BAR ASSEMBLY | 1 |
| 7 | BR-FL16 | 1" FLANGE BEARING ( 2 16 - 8" X 1 2" HEX BOLT | 4 |
| 8 | P320-000 | DESTICKER CHAIN | 1 |
| 8 | C306-002 | TAKE UP FLOATER SPROCKET BUSHING 1 17 - 8" X 4" CARRIAGE BOLT | 2 |
| 9 | P602-000 | DESTICKER MOTOR ASSEMBLY | 1 |
| 9 | C306-003 | TAKE UP FLOATER SPROCKET 1 18 - 8" X 1 4" CARRIAGE BOLT | 2 |
| 10 | P301-011 | TAKE UP LOCK PLATE 1 19 - 4" X 8" PANHEAD ALLEN 8 PAGE | 7 |
