Diagram · Thomas Thomas Desticker Blower

Tap a circled number on the diagram to identify the part.

diagram
✕
#Part numberDescriptionQty
1 E12-560-001 VALVE TO CROSS PORT RETURN
2 E12-560-002 VALVE TO CROSS PORT SUPPLY
3 E12-560-003 LATCH CYL. BUTT END TO CROSS PORT
4 E12-560-004 LATCH CYL. ROD END TO CROSS PORT
9 E12-560-006 PIPE TO HOOD CYLINDER ROD END D DRIVE MOTOR RETURN PIPE
10 E12-560-007 PIPE TO HOOD CYLINDER BUTT END E HOOD CYLINDER ROD END PIPE
11 E12-560-008 PIPE TO RIGHT SWING CYLINDER F HOOD CYLINDER BUTT END PIPE
12 E12-560-009 PIPE TO LEFT SWING CYLINDER G SWING CYLINDER DRIVER SIDE PIPE
13 E12-560-010 HOOD CYLINDER BUTT ENDS H SWING CYLINDER PASSENGER SIDE PIPE
16 E12-560-012 PUMP TO VALVE L E12-610-200 GROUND DRIVE CONTROL VALVE (3' 180°)
17 E12-560-013 VALVE TO MOTOR PIPE PRESSURE M E11-610-200 GROUND DRIVE CONTROL VALVE (2' 180°)
18 E12-560-014 PIPE TO LOWER MOTOR N HYD-FC51-10 FLOW CONTROL VALVE (2' 180°)
19 E12-560-015 VALVE TO MOTOR PIPE RETURN P HYDP-M1543SNG METARIS MHP330A497 SINGLE STAGE PUMP
20 E12-560-016 LOWER MOTOR TO PIVOT MOTOR Q HYDF-SE10 ZINGA SE-10 HYDRAULIC FILTER
21 E12-560-017 PIVOT MOTOR TO PIPE R HYDOC-003 OIL COOLER
22 E11-560-020 TANK TO PUMP (2' 180°) S HYDTR-2006 STEERING CYLINDER & DOCKING LATCH CYLINDER
23 E12-560-021 TANK TO PUMP (3' 180°) T HYDTR-2008 HOOD CYLINDER
24 E12-560-022 COOLER RETURN TO TANK TEE U HYDTR-2024 SWING CYLINDER
25 E12-561-001 GD VALVE RETURN TO OIL COOLER V HYDTR-3020 LIFT CYLINDER
26 E12-561-002 PRIORITY BLOCK TO GD VALVE W HYDM-TF0475 LOWER DRIVE MOTOR (3' 180°)
33 E12-561-006 VALVE TO TANK TEE (GD CONFIGURATION) AD HYDBC-CDM1575 PRIORITY BLOCK ASSEMBLY
36 E11-561-002 GD VALVE TO STEERING CYL. BUTT END AG HYDV-GRP51A GRESEN PRESSURE RELIEF VALVE
37 E11-561-003 GD VALVE TO STEERING CYL. ROD END AH HYDV-PC025 PRINCE PRESSURE RELIEF VALVE
40 E11-561-006 MAIN VALVE TO FLOW CONTROL
41 E11-561-007 FLOW CONTROL TO GD VALVE
42 E11-561-008 GD VALVE TO FLOW CONTROL TEE
43 E11-561-009 FLOW CONTROL TEE TO TANK
