E12-561-004 · Thomas Thomas Desticker Blower
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | E12-560-001 | VALVE TO CROSS PORT RELIEF ROD END 1 17 GD VALVE TO LEFT SWING PIPE | 1 |
| 2 | E12-560-002 | VALVE TO CROSS PORT RELIEF BUTT END 1 18 E12-561-006 GRESEN VALVE TO TANK TEE | 1 |
| 7 | E12-560-012 | HYDRAULIC PUMP TO VALVE 1 23 - O-RING TO MALE JIC (202702-12) | 1 |
| 8 | E12-560-013 | VALVE TO MOTOR PIPE PRESSURE 1 24 - O-RING TO MALE JIC 90° (2062-8-6) | 2 |
| 9 | E12-560-015 | VALVE TO MOTOR PIPE RETURN 1 25 - O-RING TO MALE JIC 90° (2062-10) | 2 |
| 10 | E12-561-001 | GD VALVE RETURN TO OIL COOLER 1 26 - O-RING TO MALE JIC 90° (2062-12) | 1 |
| 11 | E12-561-002 | PRIORITY BLOCK TO GD VALVE 1 27 - | 16 |
