13 B551-000 Complete Bump/Coast Valve Assembly · Thomas Thomas Nut Bankout (2023)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | B551-001A | BUMP/COAST VALVE MOUNTING BRACKET | 1 |
| 2 | HYDBC-B002 | BUMP/COAST VALVE BLOCK | 4 |
| 3 | HYDBC-S101 | BUMP/COAST SOLENOID CARTRIDGE | 2 |
| 4 | HYDBC-S102 | BUMP/COAST SOLENOID COIL | 2 |
| 5 | HYDBC-PR001L | BUMP/COAST RELIEF - LONG | 1 |
| 6 | HYDBC-PR001S | BUMP/COAST RELIEF - SHORT | 1 |
| 13 | B551-000 | COMPLETE BUMP/COAST VALVE ASSEMBLY | 1 |
