Air Filter Vacuum Kit · Thomas Thomas Nut Bankout (2023)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | B505-300 | COMPLETE AIR FILTER VACUUM KIT | 1 |
| 1 | B508-000 | DRIVELINE ASSEMBLY CUMMINS/CAT (2008 - 2020) | |
| 1 | B508-000 | CUMMINS/CAT DRIVELINE (2008 - 2020) | 1 |
| 2 | B505-301 | LONG VACUUM PIPE | 1 |
| 2 | B508-000X | DRIVELINE ASSEMBLY JOHN DEERE (PRE-2008) | |
| 2 | B508-000X | JOHN DEERE DRIVELINE (PRE-2008) | 1 |
| 3 | B505-302 | SHORT VACUUM PIPE | 1 |
| 3 | B508-000C | -DRIVELINE ASSEMBLY COMER/CAT (2021 - CURRENT) | |
| 3 | B508-000C | COMER/CAT DRIVELINE (2021 - CURRENT) | 1 |
| 4 | B505-303 | 1 4" 90 PVC COUPLER | 3 |
| 4 | B508-100 | DRIVELINE U-JOINT | 2 |
| 5 | B505-304 | AIR FILTER VACUUM HOSE | 1 |
| 5 | B508-100C | COMER DRIVELINE U-JOINT | 2 |
