Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| - | CA36-201-002 | THERMOSTAT | 1 |
| - | CA36-201-003 | WATER TEMPERATURE SENDING UNIT 1 25 - M8 X 70 HEX BOLT | 4 |
| - | CA36-201-004 | LOW COOLANT SENSOR 1 26 - M8 LOCK WASHER | 4 |
| - | CA36-202-004 | FUEL RAIL PRESSURE SENSOR 1 27 - M10 X 30 HEX BOLT | 24 |
| - | CA36-203-006 | OIL PRESSURE SENDING UNIT 1 28 - M10 LOCK WASHER | 24 |
| - | CA36-204-001 | FUEL FILTER 1 29 - M12 X 30 HEX BOLT | 14 |
| - | CA36-204-003 | FUEL-WATER SEPARATOR FILTER | 1 |
| - | CA36-400-101 | CAT 3.6 ENGINE WIRE HARNESS | 1 |
| - | CA36-401-001 | BAROMETRIC PRESSURE SENSOR | 1 |
| - | CA36-401-002 | ENGINE SPEED SENSOR | 1 |
| 1 | C45-101-000 | REAR ENGINE MOUNT (SIDE SPECIFIC) | 2 |
| 2 | C36-101-000 | FRONT ENGINE MOUNT | 2 |
| 3 | ENG-C001 | ENGINE ISOLATOR 4 | 1 |
| 4 | CA36-200-001 | CAT 3.6 STARTER | 1 |
| 5 | CA36-200-003 | ALTERNATOR | 1 |
| 6 | CA36-201-001 | WATER PUMP | 1 |
| 7 | CA36-204-002 | OIL FILTER 1 30 - M12 LOCK WASHER | 14 |
| 8 | CA36-207-001 | CAT 3.6 FAN | 1 |
| 9 | CA36-207-002 | FAN SPACER | 1 |
| 10 | CA36-207-003 | FAN PULLEY | 1 |
| 11 | CA36-208-001 | PUMP MOUNT PLATE | 1 |
| 12 | C45-208-002 | FLEX PLATE | 1 |
| 13 | CA36-209-001 | SERPENTINE BELT | 1 |
| 14 | CA36-209-002 | BELT TENSIONER | 1 |
| 15 | CA36-209-003 | IDLER PULLEY | 1 |
| 16 | AC13-000 | A/C COMPRESSOR | 1 |
| 17 | CA36-207-006 | AIR FILTER HARD LINE MOUNT | 1 |
