1 3 Hoist Cylinder Seal Rebuild Kit Includes · Thomas Thomas Bankout
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | HYDHC-100-000 | BANKOUT HOIST CYLINDER ASSEMBLY | 2 |
| 2 | HYDHC-101-000 | HOIST CYLINDER BODY | 1 |
| 3 | HYDHC-102-000 | HOIST CYLINDER HEAD NUT | 1 |
| 5 | HYDHC-102-101 | HEAD NUT O-RING | 1 |
| 6 | HYDHC-102-102 | 3 " HEAD NUT SEAL GASKET | 1 |
| 7 | HYDHC-102-103 | 3 " HEAD NUT WIPER GASKET | 1 |
| 8 | HYDHC-103-001 | CYLINDER TUBE - STAGE | 1 |
| 9 | HYDHC-103-002 | STAGE 1 SPIRAL LOCK RING | 1 |
| 10 | HYDHC-103-101 | 2 3 " STAGE 1 SEAL GASKET | 1 |
| 11 | HYDHC-103-102 | 2 3 " STAGE 1 WIPER GASKET | 1 |
| 12 | HYDHC-103-201 | STAGE 1 GUIDE CLIP | 1 |
| 13 | HYDHC-104-001 | CYLINDER TUBE - STAGE | 2 |
| 14 | HYDHC-104-002 | STAGE 2 SPIRAL LOCK RING | 1 |
| 15 | HYDHC-104-101 | 2 " STAGE 2 SEAL GASKET | 1 |
| 16 | HYDHC-104-102 | 2 " STAGE 2 WIPER GASKET | 1 |
| 17 | HYDHC-104-201 | STAGE 2 GUIDE CLIP | 1 |
| 18 | HYDHC-105-001 | CYLINDER TUBE - STAGE | 3 |
| 19 | HYDHC-105-201 | STAGE 3 GUIDE CLIP | 1 |
| 20 | HYDHC-106-000 | UPPER HOIST CYLINDER BUSHING ASSEMBLY | 1 |
| 23 | HYDHC-100-100 | COMPLETE HOIST CYLINDER SEAL KIT | 1 |
