← Jackrabbit Yard Dog 36/36 Elevator (Deutz)
Hydraulics: · Jackrabbit Jackrabbit Yard Dog 36/36 Elevator (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 650 | 29409A | Cross Conv. Seal | 1 |
| 651 | 27583 | WARNING (Decal) | 2 |
| 652 | 26231 | Shield for Sprockets, UHMW | 2 |
| 653 | 26232 | Outer Shield for Sprockets, Metal | 4 |
| 654 | 28553 | Linear Actuator | 1 |
| 660 | 26157A | Drive Pulley (Conveyor) 24” | 1 |
| 661 | 26158A | Idler Pulley (Conveyor) 24” | 1 |
| 668 | 26493 | Climax Coupler 1” (CC-100-100) | 3 |
| 669 | 24395D | Torque Arm, WoodChuck | 1 |
| 670 | 26622 | Side Seal 6” x 24” | 2 |
| 671 | 27373 | Slide Kit (#472-475) | 1 |
| 673 | 26129 | Upper Chain Slide | 4 |
| 674 | 25386 | Short Upper Slide | 4 |
| 675 | 24491 | Exhaust Slide (Incline) | 2 |
