← Jackrabbit Yard Dog 36/36 Elevator (Deutz)
Jackrabbit · Jackrabbit Jackrabbit Yard Dog 36/36 Elevator (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | 26097 | Exhaust Chute-Winkie (weldment) | 1 |
| 3 | 27354 | Winkie Cylinder (2” x 8”) | 1 |
| 4 | 26034 | Motor (incline belt) | 1 |
| 5 | 29502 | Split Coupler 1-1/2” ID | 1 |
| 7 | 27352 | Clamping Collar | 1 |
| 8 | 28441 | Upper Drive Pulley 36” W/LG. & Shaft | 1 |
| 9 | 22097 | Bearing (1-1/2” pillow block) | 2 |
| 10 | 28440 | Snub Roller 36” length | 1 |
| 11 | 23524 | Flangette Bearing for snub roller | 2 |
| 12 | 28512 | (36” x 65’ 8”) Giant Z Incline Belt | 1 |
| 13 | 28506 | Idler Roller 36 – 3/8” length, (return roller) | 8 |
| 14 | 28417 | Idler Pulley, Incline belt (lower) 36” | 1 |
| 15 | 28518 | Bearing for Idler pulley | 2 |
| 16 | 28474 | Belt Wipers (UHMW) 36” Incline Belt | 2 |
| 17 | 27882 | Transition Side Seal 1/8”x 2” x 16” (replaces 16” brush) | 2 |
| 19 | 28437 | Incline Pan Long 240” | 1 |
| 19 | 28499 | Incline Pan Short 120” | |
| 19 | 28821 | Pulley End Cover | 1 |
| 19 | 28452 | Extension Incline Pan x 23-1/2” | 1 |
| 19 | 28451 | Extension Lower Incline Pan x 18 ½” | 1 |
