← Jackrabbit Yard Dog 36/36 Elevator (CAT 2.8L)
Woodchuck (Option) · Jackrabbit Jackrabbit Yard Dog 36/36 Elevator (CAT 2.8L)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| G11 | GI 29519 GIANT Z BELT 24X221 | ||
| G2 | 29409A | CROSS CONVEYOR SEAL | |
| G3 | 29517 | SEAL HOLD DOWN | |
| G4 | 29357 | CROSS CONVEYOR MOTOR | |
| G6 | 26493 | COUPLER SPLIT I" | |
| G7 | 22977 | BRG PILLOW BLOCK I" | |
| G8 | 26464D | BEARING PUSHER | |
| G9 | 26464B | BEARING PULLER | |
| H1 | 66075 | DISPLAY | |
| H2 | 22416 | KEY IGNITION SWITCH | |
| H3 | 66076 | BUTTON PAD, TOGGLES, CAN - 2 X | 4 |
| H4 | 68577 | BUTTON PAD, TOGGLES, CAN - 2 X | 3 |
| 11 | 67491 | V2YD TOW FRAME | |
| 12 | 61749 | RIM | |
| 13 | 61748 | TIRE | |
| 14 | 61750 | TIRE AND RIM ASSEMBLY | |
| 15 | 25659 | LED LIGHT | |
| 16 | 26199 | 1" DOUBLE HYCON CLAMP | |
| 17 | 56326 | 03/8" DOUBLE HYCON CLAMP | |
| 18 | 26766A | SEAT#55TBL |
