← Jackrabbit Yard Dog 36/36 Elevator (CAT 2.8L)
Upper Chute Section‐ Walnut Rod Belt · Jackrabbit Jackrabbit Yard Dog 36/36 Elevator (CAT 2.8L)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| C2 | 25659 | LED LIGHT | |
| C3 | 28354 | TIE ROD 3014 | |
| C4 | 28239 | HELAC ROTARY ACTUATOR | |
| C5 | 60859 | FRONT WHEEL DRIVE TIRE ASSEMBLY (BIN END) | |
| D2 | 66220 | BATTERY KIT | |
| D3 | 27248 | INTAKE TUBE CLAMP | |
| D5 | 66549 | AIR INTAKE TUBE | |
| D6 | 66201 | ENGINE CONTROL MODULE | |
| D7 | 66173 | AMBIANT AIR TEMP SENSOR | |
| D8 | 56600 | AIR FILTER HOUSING | |
| D9 | 33898 | PRIMARY AIR FILTER | |
| DI0 | 33899 | SECONDARY AIR FILTER | |
| D14 | 733-5794 3" MUFFLER CLAMP | ||
| D20 | 29576 | AIR INTAKE ELBOW | |
| D21 | 66547 | RUBBER INSERT | |
| D4 | 60162 | RUBBER INTAKE TUBE | |
| D12 | H212 EXHAUST CLAMP | ||
| D13 | 66039 | LOWEREXHAUSTTUBE | |
| D15 | 66164 | FUEL FILTER | |
| D16 | 68584 | HYDRAULIC CONTROLLER MODULE | |
| D17 | 66090 | RUBBER INTAKE TUBE CLAMP- 3.94 -4.25 | |
| D18 | 28339 | PRE CLEANER EX-30 | |
| D19 | 30659 | REDUCING ELBOW | |
| D22 | NIA 2.5" - 4.5" DIA WORM DRIVE CLAMP | ||
| D23 | 61719 | FUEL GAUGE |
