← Jackrabbit PC 20-30 Pre-Cleaner (Deutz)
Mics. Parts · Jackrabbit Jackrabbit PC 20-30 Pre-Cleaner (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 28336 | Tire Rim | ||
| 27020B | Tire | ||
| F1 | 28784 | Remote Kit | |
| F2 | 28247 | Remote Receiver | |
| F3 | 28246 | Remote Transmitter | |
| F4 | 28487 | Antenna Mount | |
| F6 | 28489A | Gigalink Cable | |
| F7 | 28489 | Coax Cable | |
| F5 | 28488 | Antenna | |
| G1 | 29726 | Sun Vented Relief | |
| G2 | 27386 | Strainer GPM | |
| G3 | GC079 | Desticker Pump | |
| G4 | GC086 | Non Desticker Pump | |
| G5 | 29358 | RS/WR 18 | |
| G5A | 29357A | RS/WR 10/18 SEAL KIT | |
| G6 | 29357 | RS/WR 10 | |
| 27762 | Drive Plate Kit | ||
| G8 | 27317 | Frda Xan | |
| G8A | 27317A | Frda Xan Seal Kit | |
| G9 | 29555 | Valve (SV-10) | |
| G10 | 27312 | Valve Coil | |
| G11 | 29554 | Valve (SV-16) | |
| G12 | 27314 | RPEC Fan | |
| G13 | 27314A | RPEC Fan Seal Kit | |
| G14 | 23548A | Hydraulic Filter | |
| G15 | 28842 | Hydraulic Fluid Cap | |
| G16 | 24669 | Sight Level Gage | |
| G17 | 24671 | Strainer 15GPM 2"x1.25" | |
| G18 | 27386 | Strainer 15GPM 1.5"x1" | |
| G19 | 26612 | 2"x24" Cylinder | |
| G20 | 26199 | 1" Double Clamp | |
| G21 | 26034A | MLHT 500 | |
| G22 | 26242 | RE 18 |
