← Jackrabbit PC 20-30 Pre-Cleaner (Deutz)
Engine Parts · Jackrabbit Jackrabbit PC 20-30 Pre-Cleaner (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| C1 | 27014 | Air Filter Inner (Don. P829332) | |
| C2 | 27013 | Air Filter-Outer (Don. P827653) | |
| C3 | 27015 | Air Filter Assemble G0700018 | |
| 27015A | Air Filter Mounting Band P777731 | ||
| C4 | 27015B | Air Filter Vacator Valve P158914 | |
| C5 | 28795 | Restriction Indicator (Deutz) | |
| C6 | 27013A | Filter Housing End Cover (P636202) | |
| C7 | 27011 | Fuel Filter (Duetz 117-4696) | |
| C8 | 27943 | Fuel Strainer in line 117-8753 | |
| C9 | 27010 | Oil Filter (Duetz 117-4416), F2L 1101 &2011 | |
| C10 | 28158 | Dip Stick (427-2816) 3 Cyl | |
| C11 | 27168A | Fan Belt (Duetz 117-9565) | |
| C12 | 27202D | Fuel Shut off Solenoid (0428-7583) | |
| C13 | 27203C | Fuel Pump (428-6113), F2L, F3L, F4L 2011 | |
| C14 | 27492 | Fuel Injector Return Line Kit 0417-8631 | |
| 28419D | Fuel Injector Return Line Per Foot 0417-8632 | ||
| C15 | 27656 | Throttle Solenoid (1756E) | |
| C16 | 27657 | Coil Commander (SA4667) | |
| C17 | 27310 | Throttle Linkage Kit, assembly | |
| C17A | 24744C | Throttle Ball Joint, 90 degree | |
| C17B | 24744D | Throttle Hex Spacer | |
| C17C | 24744E | Throttle Straight Connection | |
| C18 | 27776 | Throttle Lever 417- 9754 for Duetz 1011 | |
| C19 | 27803B | Alternator New 01182434 for 2, 3, 4 Cyl Eng. | |
| 25026 | Exhaust Pipe | ||
| 24752 | Exhaust Pipe Hanger | ||
| C20 | 27959 | Rubber Ring Isolator Duetz Engine | |
| 27407 | Oil Cooler for 3 Cylinder Engine | ||
| C21 | 27876A | Oil Pressure Sender (CH86281) three prong | |
| C22 | 22424 | Hour Meter | |
| 27762 | Drive Plate Kit, (Drive & Bell Housing Cover) | ||
| C23 | 29564 | Drive Plate | |
| C24 | 27285 | Gas Shock for Engine Door |
