Engine Parts (Continued) - Fotos C1-C24 · Jackrabbit Jackrabbit PC 20-30 Pre-Cleaner (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| D1 | 26403 | Rocker Switch (1TP4-2) Throttle & Belt | |
| D2 | 27527 | Toggle Switch (1TL1-2) @ Momentary | |
| D3 | 28213 | Toggle Switch (1NT1-7) @ Momentary on/off | |
| D4 | 22416 | Key Switch (Polak 331-196) | |
| 22416A | Key Polak for 22416 | ||
| D5 | 27131A | Engine Oil Temperature Gauge 2" hole | |
| D6 | 27876A | Oil Pressure Sender (CH86218) three prong | |
| D7 | 27145 | Deutz Idiot Light Assembly (Red) | |
| D8 | 27145A | Deutz Idiot Light Assembly (Green) | |
| D9 | 27123 | Light Bulb Only | |
| D10 | 26399 | Circuit Breaker 30 AMP | |
| D11 | 24564 | Electrical Wiring Harness for 20/30 | |
| D12 | 27657 | Timer Module | |
| D13 | 27118 | Switch, Jack-Chute Momentary | |
| D14 | 27202D | Solenoid W/ O-Ring, Fuel Shut Off | |
| 27203B | Solenoid O-Ring | ||
| D15 | 27656 | Solenoid, Throttle | |
| D16 | 22424 | Hour Meter | |
| D17 | 27803B | Alternator |
