Incline Conveyor (Continued) - Fotos A11-A20 · Jackrabbit Jackrabbit PC 20-30 Pre-Cleaner (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| B1 | 22977 | Bearing (VAK 1" Pillow Block) | |
| B8 | 24340A | Drive Roller 20 1/4" W/Lag | |
| B2 | 26464 | Bearings Pad | |
| B10 | 25070 | 20-3/8" x 1-3/4" Idler Roller | |
| 27307 | Bearing Housing For 20-3/8" x 1-3/4" Idler roller | ||
| 27306 | Bearings for 20-3/8" x 1-3/4" Idler Roller | ||
| B11 | GC057 | (20" x 412") Horizontal Belt | |
| 27377 | (20" x 316") Horizontal Belt Front Wheel Drive | ||
| B12 | 27523 | 20" Belt Lacing Pin | |
| B9 | 24556 | Belt Wiper UHMW 27 3/4" | |
| B6 | 26765 | Transition Seal UHMW | |
| B5 | 29104 | Lower Hyd. Motor (RE-18) | |
| 27553 | Seal Kit Motor for (RE-18) | ||
| B3 | 26493 | Belt Drive Coupler 1" | |
| B4 | 28935 | Torque Arm | |
| GC037 | 20" x 56" Rear Belt Skid Pan (Welded Replacement) | ||
| 24371 | 20" x 64 1/2" Front Belt Skid Pan (Welded Replacement) | ||
| B7 | 26045A | 20" Bin Extension Upper |
