← Jackrabbit CO-Jack (s/n 425+)
Co-Jack Parts - Mineral Oil Tank · Jackrabbit Jackrabbit CO-Jack (s/n 425+)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| A | 24751 | OIL TANK CAP | |
| B | 58729 | 1/4" MINERAL OIL TANK SIGHT HOSE | |
| C | MB MJ 6-4 | 1/4" MALE BOSS, 1/4" MALE JIC FITTING | |
| D | MP FJX 2-4 | 1/8" MALE PIPE, 1/4" FEMALE JIC SWIVEL FITTING | |
| E | 58481 | NEEDLE VALVE WITH SIGHT GLASS | |
| F | 57768 | 1/4" RUBBER MINERAL OIL HOSE | |
| G | 57861 | 1" MALE PIPE, 1/2" FEMALE PIPE TANK STRAINER | |
| H | 57811 | SUN BODY | |
| I | 57812 | SUN CARTRIDGE & COIL | |
| A | 57928 | DISPENSING WAND WELDMENT | |
| B | 57817 | COJACK RIM | |
| C | 57818 | COJACK WHEEL | |
| D | 58691 | COJACK AXLE | |
| E | 22424 | ENGINE HOUR METER | |
| F | 67469 | VACUUM PUMP | |
| G | 67470 | PARTICLE FILTER STAINLESS STEEL ELEMENT | |
| H | 63670 | COJACK SKID WELDMENT [OPTION NOT SHOWN] |
