Electrical Schematic - Wire Sizes And Locations · Jackrabbit Jackrabbit CO-Jack (s/n 425+)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| A | 57935 | 1/2" 100FT HOSE REEL | |
| B | 57951 | 1/2" 100 FT RUBBER AIR HOSE | |
| C | 57935 | 1/2" 50 FT REEL | |
| D | 57950 | 1/2" 50 FT RUBBER AIR HOSE | |
| E | 57970 | 1/2" LEFT SIDE ROOF AIR HOSE | |
| F | 57972 | 1/2" BACK SIDE ROOF AIR HOSE | |
| G | 57971 | 1/2" CENTER ROOF AIR HOSE | |
| H | 57970 | 1/2" RIGHT SIDE ROOF AIR HOSE | |
| I | 24751 | OIL TANK CAP | |
| J | 57995 | PIN LOCK | |
| K | 58654 | 1/2" MINI BALL VALVE FEMALE, FEMALE | |
| L | MJ MP 8-8 | 1/2" MALE JIC, 1/2" MALE PIPE FITTING |
