Air Filter · Jackrabbit Jackrabbit JR 400 (s/n 645-822)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 27552B | BROWN MIXED 1GA | ||
| 27552BB | BROWN NOT MIXED 3/4 GA | ||
| 27552A | BEIGE MIXED 1 GA | ||
| 27552AA | BEIGE NOT MIXED 3/4 GA | ||
| 27552D | ACCELERATOR 2OZ | ||
| 27552C | ACCELERATOR QT. | ||
| 25750A | BROWN SRAY PAINT | ||
| 25750 | BEIGE SPRAY PAINT | ||
| 27552 | PRIMER MIXED | ||
| 148 | 27239 | AIR FILTER ASSY | |
| 149 | 27238 | SCEONDARY AIR FILTER | |
| 150 | 27237 | PRIMARY AIR FILTER | |
| 151 | 27239A | END CAP FOR AIR FILTER | |
| 152 | 27405 | VACATOR VALVE | |
| 153 | 27176 | RESTRICTION INDICATOR | |
| 154 | 27239C | MOUNTING BAND | |
| 155 | 26939 | TURBO PRECLEANER | |
| 156 | 28959 | FUEL FILTER | |
| 157 | 28955 | FUEL WATER SEPERATOR | |
| 158 | 28973 | OIL FILTER | |
| 159 | 27001 | SECONDARY FUEL FILTER | |
| 160 | 27002 | INLINE FUEL FILTER | |
| 161 | 27167 | FUEL SHUT OFF SOLENOID | |
| 162 | 28409 | FUEL LIFT PUMP | |
| 163 | 28409A | FUEL LIFT PUMP GASKET | |
| 164 | 27261 | ENGINE ISOLATOR | |
| 165 | 27135D | RADIATOR | |
| 166 | 27135E | RADIATOR CAP | |
| 167 | 27945 | UPPER RADIATOR HOSE | |
| 168 | 27944 | LOWER RADIATOR HOSE | |
| 169 | 27754A | WATER PUMP | |
| 170 | 28974 | ENGINE FAN | |
| 171 | 28962 | STARTER | |
| 172 | 27009A | ALTERNATOR | |
| 173 | 28965 | BELT TENSIONER | |
| 174 | 28961 | SERPENTINE BELT | |
| 175 | 28966 | OIL PAN | |
| 176 | 28967 | OIL PAN GASKET | |
| 177 | 28963 | DIP STICK | |
| 178 | 28964 | DIP STICK HOLDER | |
| 179 | 28797 | OIL DRAIN PLUG | |
| 180 | 28798 | DRAIN PLUG WASHER | |
| 181 | 26359 | EXHAUST PIPE WITH BELLOWS | |
| 182 | 26239 | REXROTH GROUND DRIVE MOTOR | |
| 183 | 26239A | GROUND DRIVE SHAFT SEAL | |
| 184 | 26239B | CONTROL COIL SMALL | |
| 185 | 26239C | CONTROL COIL LARGE | |
| 186 | 26239D | DIN CONNECTOR | |
| 187 | 27408 | FRONT PUMP | |
| 188 | 27408B | FRONT PUMP CONTROL | |
| 189 | 27408A | FRONT PUMP SPACER | |
| 190 | 28774 | THRU DRIVE O RING LARGE | |
| 191 | 28773 | THRU DRIVE O RING SMALL | |
| 192 | 26397 | PRESSURE SWITCH | |
| 193 | 25711 | BIN CYLINDER | |
| 194 | 25711A | BIN CYLINDER SEAL KIT WITH BUSHINGS | |
| 195 | 27354 | BIN FLAP CYLINDER | |
| 196 | 27780 | BIN FLAP CYLINDER SEAL KIT | |
| 197 | 27160 | FOOT PEDAL | |
| 198 | 28789 | FOOT PEDAL BUSHING | |
| 199 | 27382 | FOOT PEDAL SEAL KIT | |
| 200 | 28789A | FOOT PEDAL SPRING | |
| 201 | 26393B | BODY PARKING BRAKE | |
| 202 | 26393A | CARTRIDGE PARKING BRAKE | |
| 203 | 26393C | PARKING BRAKE COIL | |
| 204 | 27816 | PD 343 TEST PORT FITTING | |
| 205 | 27817 | PD341 TEST PORT FITTING | |
| 206 | 28308 | REAR PUMP | |
| 207 | 27006A | CHARGE FILTER | |
| 208 | 23548A | HYRAULIC FILTER | |
| 209 | 29724 | AIR BAG | |
| 210 | 29724A | AIR BAG HOSE KIT | |
| 211 | 29723 | GAS SHOCK |
