Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 163 | 27182 | Hydraulic Tank Filler Cap | 1 |
| 164 | 24669 | Sight Level Gauge (LSP-151-04) | 2 |
| 252 | X X 283 - X | ||
| 254 | - X 284 - X | ||
| 258 | - X 285 X X | ||
| 259 | - X 286 X X | ||
| 260 | X X 287 X X | ||
| 261 | - X 288 X X | ||
| 264 | - X 289 X X | ||
| 265 | - X 291 - X | ||
| 267 | - X 296 X X | ||
| 268 | - X 306 X X | ||
| 269 | X X 307 X X | ||
| 270 | X X 311 - X | ||
| 274 | - X 312 - X | ||
| 275 | - X 317 X X | ||
| 276 | - X 320 - X | ||
| 277 | - X 322 X X | ||
| 278 | - X | ||
| 279 | - X | ||
| 400 | 28253 | Adapter Fitting (MJ FJ 12-20) for motor 26239 | 1 |
| 405 | 24664 | Auger Motor RS180201 / 2003001 | 2 |
| 406 | 27801 | Auger Control Valve SP11, joy stick in cab | 1 |
| 408 | 25278 | Clamps ¾” (Hycon) | 2 |
| 410 | 28940 | Cylinder (Bin Lift Multi-Stage) w/stop tube 437--- | 1 |
| 411 | 27089 | Cylinder Power Steering 97--- | 1 |
| 412 | 27354 | Cylinder HPTR2008, for bin flap | 1 |
| 415 | 27006 | Filter for Charge Pump (H830024) 1-73 | 1 |
| 416 | 23548A | Filter Hydraulic Element (LHS SPE 50-10) | 2 |
| 420 | 27160 | Foot Pedal (Hydraulic Control) | 1 |
| 422 | 22026 | Motor Steering (Dan Foss) | 1 |
| 425 | 26239 | Motor Rex Roth (AA6VM---) ground drive | 1 |
| 425A | 28251 | Motor Sunstrand (51V160---) ground drive | 1 |
| 425B | 28255 | Anti Braking Valve, Cartage (SV10-40-0-N-0) | 1 |
| 425C | 28254 | Anti Braking Valve, Body (702-4460) | 1 |
| 425D | 28256 | Anti Braking Coil (63560 12) | 1 |
| 426 | 26397 | Pressure Switch (Nason PX-1C70R/8-32) | 1 |
| 429 | 27869 | Parking Brake | 1 |
| 429A | 26393A | Waterman Cartridge (12C348) parking brake | 1 |
| 430 | 27408 | Pump Front, Rex Roth (AA4VG56---) | 1 |
| 430A | 28192 | Pump Front, Sunstrand (9TRO8----) | 1 |
| 432 | 27409 | Pump Rear CSI (P17A196---) | 1 |
| 450 | 27888 | Manifold Assemble | 1 |
| 450A | Coil (6391012) | 1 | |
| 450B | Cartridge (SV08-21-N-00) | 1 | |
| 450C | Body (7024660-6SAE) | 1 | |
| 451 | 27889 | Wheel Motor Rex. (MCR5F308F---) | 2 |
| 452 | Hub Fairfield (W1A440318) | 2 | |
| 453 | Motor Cessana (74111-DAC) | 2 | |
| 454 | Cover, Single Speed (174557MCRSREAL) | 2 | |
| 455 | Cover Plate “O” Ring (853216) | 2 | |
| 456 | PR. Reducing Valve (PRO8-32A-O-N-03/00.5) | 1 | |
| 457 | Sensor (NBB2-8GM40----) | 1 | |
| 458 | Bracket (BF-8) | 1 | |
| 459 | Switch (IFMR0036) | 1 | |
| 460 | V1-W- 10M-PVC | 1 | |
| 461 | V1-W- 10M-PUR Cable | 1 | |
| 462 | V1-W- 5M-PUR Cable | 1 |
