← Jackrabbit JR 400 (s/n 1-644)
Jackrunner · Jackrabbit Jackrabbit JR 400 (s/n 1-644)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 27 | 27323 | AC Compressor Mounting Bracket 137 - 436 | 1 |
| 28 | 27894 | AC Belt Tension Kit 137 - 436 | 1 |
| 29 | 27893 | AC Belt Tension Pulley 137 - 436 | 1 |
| 30 | 27323 | AC Compressor Mounting Bracket 1 - 136 | 1 |
| 31 | 27472 | AC Compressor Take-up Weldment 1 – 136 | 1 |
| 32 | 26878 | AC Take Bolt 4-1/2” 1 – 136 | 1 |
| 33 | 26876 | AC Tension Block (see 27893) 1 – | 136 |
| 34 | 28812 | Air Conditioner Belt (9420) 437--- | 1 |
| 300 | 28960 | QS 4.5 – C110 Cummins Turbo, 110 HP @ 2500RPM | 1 |
| 301 | 27237 | Air Filter Primary (P781039) 48--- | 1 |
| 301 | 27237 | Air Filter - Outer (Donaldson P781039) 48-63 | 1 |
| 302 | 27238 | Air Filter Safety (P777639) 48--- | 1 |
| 302 | 27238 | Air Filter - Inner (Donaldson P777639) 48-63 | 1 |
| 303 | 27239 | Don Air Filter G 10 02 | 97 |
| 304 | 27239A | End Cap Filter Housing (P538200) 48--- | 1 |
| 305 | 27250 | Donaldson Replacement for FleetGuard 1-47 | |
| 305 | 27544 | Mounting Band P007191 | 1 |
| 306 | 27405 | Vacuator Valve (Donaldson P776008) | 1 |
| 307 | 27176 | Restriction Indicator (3304584-S) | 1 |
| 310 | 26939 | Pre-Cleaner Engine (turbo 11 model 35) | 1 |
| 315 | 27009A | Alternator (498 8274 / 428000-2920) 137--- | 1 |
| 315A | 27009C | Alternator Pulley 437--- | 1 |
| 318 | 27659 | Coolant Harness (low) Cummins | 1 |
| 319 | 28963 | Dip Stick, Cummins engine (493 2925) 437--- | 1 |
| 322 | 28622 | Exhaust Pipe 437--- | 1 |
| 324 | 27974 | Fan, Cummins 449-100-20” 437--- | 1 |
| 328 | 28959 | Fuel Filter (73073080) 437--- | 1 |
| 328A | 27002 | Fuel Filter - In Line (Fleet guard FF5079) | 1 |
| 329 | 28955 | Fuel Filter- Water Separator (FS 19732) 437--- | 1 |
| 330 | 27167 | Fuel Shut Off Solenoid (3991167) | 1 |
| 332 | 27261 | Isolator, Engine (rubber) | 4 |
| 334 | 28973 | Oil Filter (Fleet Guard LF3970) 437--- | 1 |
| 336 | 28966 | Oil Pan (4897997) 437--- | 1 |
| 340 | 28895 | Radiator / After Cooler 437--- | 1 |
| 340A | 27135E | Radiator Cap | 1 |
| 340B | 27640 | Radiator Petcock (10-145) | 1 |
| 340C | 27944 | Lower Hose, radiator | 1 |
| 340D | 27945 | Upper Hose, radiator | 2 |
| 340E | 26348 | Seal for Bin and Radiator 6”x 35 ½” | 1 |
| 340F | 27447 | Seal, Bottom of Radiator 4” x 21” | 1 |
| 340G | 28615 | Air Deflector 437--- | 1 |
| 341 | 28961 | Serpentine Belt (397-9344) 437--- | 1 |
| 342 | 28965 | Serpentine Belt Tensioner (3976834) 437--- | 1 |
| 344 | 28962 | Starter, Cummins (WET 397 1615) 437--- | 1 |
| 346 | 25941 | Throttle Cable 1-137 | 1 |
| 348 | 27549 | Thermostat (380-2968) | 1 |
| 350 | 28514 | Tubro Intake pipe 437--- | 1 |
| 350 | 27236A | Turbo Intake Pipe 1-436 | 1 |
| 350A | Intake Fitting, Rubber, (turbo intake pipe) | 1 | |
| 350B | Exhaust Fitting, Rubber (turbo intake pipe) | 1 | |
| 352 | 28969 | Water Pump, w/hard pulley 437--- | 1 |
