Jackrunner · Jackrabbit Jackrabbit JR 400 (s/n 1-644)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 8 | 27325 | Switch Fan Speed AC (71R0400) | 1 |
| 9 | 27325A | Switch for AC On-Off (71R0010) | 1 |
| 10 | 27165 | Circuit Breaker For AC 71R300 | 1 |
| 11 | 27308 | Relay AC (71 R 1902) | 1 |
| 200 | 27774 | Battery, group 65, 900 CCA 109--- | 1 |
| 200 | 26391 | Battery, (74LTV) see 27774 1-108 | 1 |
| 210 | 26410 | Bin Dump Pump, HP100 | 1 |
| 212 | 27545 | Circuit Breaker 50 AMP | 1 |
| 213 | 26399 | Circuit Breaker 30 AMP 72135 | 2 |
| 214 | 27786 | Circuit Breaker 6 AMP | 1 |
| 217 | 27948 | Diode, to stop feed back to starter | 1 |
| 220 | 27879 | Gem Cantrac, engine monitor 138--- | 1 |
| 225 | 22557 | Oil Pressure Gauge Murphy. 20-P-100 1-137 | 1 |
| 229 | Fuses Holders for electronic engine system | 2 | |
| 230 | 26409 | Hot Plug C.H. (46210-02) | 1 |
| 237 | 27428 | Head Light (hobbs 73761-11) 74--- | 3 |
| 238 | 27454 | Tail Light (red) M417 | 2 |
| 245 | 27157 | Relay, starter | 1 |
| 250 | 22416 | Switch Ignition Key (polak 31-196) | 1 |
| 251 | 26403 | Switch (1TP4-2) | 2 |
| 252 | 26404 | Switch (1TP4-6) | 1 |
| 253 | 26405 | Switch (2TP-4-1) | 1 |
| 254 | 27867 | Toggle Switch, 3 pos. idle micro int1-7 137--- | 1 |
| 255 | 27868 | Toggle Switch, 3 pos. dia. micr int1-8 137--- | 1 |
| 270 | 26398 | Terminal Block (DC 70018) | 1 |
| 275 | 26305 | Laminated Electric Wiring Diagram | 1 |
| 429A | 26393A | Waterman Cartage 12C 34S | 1 |
