← Jackrabbit JR 400 (s/n 1-644)
Jackrunner · Jackrabbit Jackrabbit JR 400 (s/n 1-644)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 105 | 28149 | Auger Assembly Right (big, bin) 235-240, 242, 243 | 1 |
| 105 | 26290 | Auger Assembly Right (std. bin) 1-234, 241, 244-297 | 1 |
| 106 | 28150 | Auger Assembly Left (big, bin) 235-240, 242, 243 | 1 |
| 106 | 26291 | Auger Assembly Left (std. bin) 1-234, 241, 244-297 | 1 |
| 107 | 22495 | Climax Coupler 1-1/4” for augers | 2 |
| 108 | 22097 | Pillow Block Bearing (1-1/2”) | 4 |
| 109 | 25854 | Motor Mount for augers | 2 |
| 115 | 27252 | Bumper UHMW #49---- | 1 |
| 116 | 27330 | Bin Extension (side) painted no cylinder | 1 |
| 117 | 24122 | Bin Pivot Pin | 4 |
| 118 | 22409 | Rod End Bearing (#VM 12G w/o fitting) safety bar | 1 |
| 120 | Axel front | 1 | |
| 121 | 27842 | Hub, for front axel | 2 |
| 122 | 26448 | Front Leaf Spring (#633401) | 2 |
| 122A | 28169A | Bolts, Front Spring, ¾’ X 5” 298--- | 4 |
| 122B | 22504B | Bushing ¾” ID 298--- | 4 |
| 122B | 22504A | Bushing 5/8” ID (5/8”x 4 ¼”bolt) 1-297 | 4 |
| 125 | 28163 | Tie Rod Assembly Weldment | 1 |
| 126 | 22414 | Vertical Socket Steering Arm | 1 |
| 127 | 27589 | Tie Rod End Rt. (Spicer R8225) | 1 |
| 128 | 27588 | Tie Rod End Lf. (Spicer R 8224) | 1 |
| 140 | 26233 | Differential (rear axel) | 1 |
| 140A | 28148 | Seal, for rear axel | 1 |
| 141 | 26449 | Rear Leaf Spring (#632447) rear axel | 2 |
| 141A | 28170A | Bolts Rear Spring, ¾” X 6” 298--- | 4 |
| 141B | 22504B | Bushing ¾” ID rear axel 298--- | 4 |
| 141B | 22504A | Bushing, solid metal (5/8”x 4 ¼”bolt) 109 -297 | 4 |
| 141A | 27813 | Bolt & Nut for 22504, 5/8” X 4 1/4” 1 - 108 | 4 |
| 141B | 22504 | Bushing (RB 81) 5/8”X 2 5/8” 1 - 108 | 4 |
| 141D | 27430 | Doubler | 2 |
| 141E | 28565 | Rubber Stop (rear springs) | 2 |
| 142 | 26081 | Drive Line | 1 |
| 142A | 26081C | Cross for U joints | 2 |
| 145 | 28167 | Spring Hanger Up Date Kit | 1 |
| 148 | Studs, front | 12 | |
| 149 | 27805 | Studs, rear | 16 |
| 150 | 27043 | Decal (JACKRABBIT 3”) | 3 |
| 152 | 28200 | Fender Right (sloped) with headlight 307--- | 1 |
| 152 | 25911 | Fender Right with headlight 1-306 | 1 |
| 153 | 28201 | Fender Left (sloped) with headlight 307--- | 1 |
| 153 | 25910 | Fender Left with headlight 1-306 | 1 |
| 154 | 25912 | Fender RT. or LT. Painted 2 colors | 1 |
| 160 | 24751 | Fuel Cap | 1 |
| 161 | 27445 | Fuel Gauge, 17” | 1 |
| 163 | 27182 | Hydraulic Tank Filler Cap | 1 |
| 164 | 24669 | Sight Level Gauge (#LSP -151-04) | 2 |
| 170 | 26348 | Seal (Bin - Radiator) 6” x 35 ½” | 1 |
| 172 | 27447 | Bottom Air Seal For Radiator | 1 |
| 173 | 26357 | Mud Flap, 14”X 26 ½” | 1 |
| 175 | 27020 | Tire 12 - 16.5 TL R-3 | 4 |
| 176 | 26236 | Rim - Front | 2 |
| 177 | 27586 | Front Rim and Tire Mounted | 2 |
| 178 | 26237 | Rim - Rear | 2 |
| 179 | 27587 | Rear Rim and Tire Mounted | 2 |
| 180 | 27874 | Rim Front, for 4 wheel drive JackRunner | 2 |
| 190 | Paint and Primer | ||
| 237 | 27428 | Head Light | 2 |
| 238 | 27454 | Tail Light | 2 |
| 405 | 27330A | Cylinder, Hoses & Fittings for bin extension | 1 |
| 411 | 27098 | Steering Cylinder 3”X 8” 97--- | 1 |
| 412 | 24664 | Auger Motor RS180201 / 2003001 | 2 |
| 429 | 27869 | Brake, parking (mico) | 1 |
