← Jackrabbit JR 400 (s/n 1-644)
Jackrunner · Jackrabbit Jackrabbit JR 400 (s/n 1-644)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 44 | 26416 | Door Handle, inside 1-49 | 1 |
| 50 | 27004 | Air Filter Assemble, (FWG 065012), cab | 1 |
| 50A | 27004A | Primary filter P 181052 | 1 |
| 50B | 27004B | Dust cap P10386 | 1 |
| 50C | 27004C | Vacuator Valve P103198 | 1 |
| 50D | 27004D | Baffle P102510 | 1 |
| 50E | 27939 | Wing Nut for filter assemble | 1 |
| 51 | 26938 | Air Filter Pre-cleaner | 1 |
| 51A | 27507 | Pre- Cleaner Bowl | 1 |
| 52 | 27348 | Air Deflector (Fresh Air Discharge) | 1 |
| 53 | 27451 | Cup Holder | 1 |
| 60 | L76188 Door Handle 303--- | 1 | |
| 60A | DE18769 Door Latch 303--- | 1 | |
| 60B | CE17973 Large Handle Gasket 303--- | 1 | |
| 60C | CE17974 Small Handle Gasket 303--- | 1 | |
| 60D | AL75503 Thumb Button 303--- | 1 | |
| 61 | 27475 | Rotor Latch, Door (11446-16) 92-302 | 1 |
| 61A | Latch Rod w/fittings 92-302 | 1 | |
| 61B | 27473 | Latch Spring 92-302 | 1 |
| 61C | 27474 | Striker Bolt (10795-16) 92-302 | 1 |
| 61D | 26272 | Bushing for door handle 92-302 | 1 |
| 61E | 27018 | Draw Latch, Door (#A1-11-702-20) 1-91 | 1 |
| 62 | 27596A | Door Seal 303--- | 1 |
| 65 | 27195 | Foam Trim | 1 |
| 67 | 28651 | Seat, Grammer Maximo 437--- | 1 |
| 67 | 27019 | Seat (WM 1242) 169 - 436 | 1 |
| 70 | 22026 | Steering Motor, steering wheel mounted on motor | 1 |
| 75 | 27879 | Throttle Cantrack Display (MC917009) 137--- | 1 |
| 75A | 27880 | Throttle Handle (MC301765-017) 137--- | 1 |
| 75A | 27881 | Throttle Control (MC311789-003) 137--- | 1 |
| 75 | 27535 | Throttle Control (Quad. Stat. Q14020, W/Handle) | |
| 80 | 25914 | Window - Small Hinged Window | 1 |
| 81 | 25915 | Window - Front | 1 |
| 82 | 25915B | Window – Front Glass | 1 |
| 83 | 25916 | Window - Rear | 1 |
| 84 | 25917 | Window - Right | 1 |
| 85 | 25918 | Window - Left | 1 |
| 86 | 27273 | Window Latches (Two/Set) 1-91 | 1 |
| 87 | 27273A | Window Sash Lock 92--- | 1 |
| 88 | 27547 | Pop Rivets (100 each) | 1 |
