Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | 26406K | Evaporator ( R8500-3P) complete | 1 |
| 2 | 26406A | Filter Screen (78R5330) | 1 |
| 3 | 26406B | Evaporator Coil only | 1 |
| 4 | 27357 | Expansion Valve (71R8300 | 1 |
| 5 | 27326 | Thermostat (71R3200) | 1 |
| 6 | 27164 | Fan Motor (73R4102) | 1 |
| 7 | 27520 | Blower Wheel (73R7000) | 1 |
| 7A | 27440 | Master Air Diffuser (72R3150-1) | 1 |
| 7B | 27449 | Hose for Diffuser 3” ID X 3” | 1 |
| 8 | 27325 | Fan Speed Control Switch (71R0400) | 1 |
| 9 | 27325A | On – Off Switch (71R0010) | 1 |
| 10 | 27165 | Circuit Breaker (71R1300) | 1 |
| 11 | 27308 | Relay (71R1902) | 1 |
| 12 | 26407 | Rec./Drier/Binary Switch (74R2586) | 1 |
| 13 | 26407A | Drier only (74R2436) | 1 |
| 14 | 27397 | Binary Switch only (71R7050 | 1 |
| 15 | 28811 | Compressor (5726) 437--- | 1 |
| 16 | 28593 | Condenser 437--- | 1 |
| 17 | 26390 | Condenser Frame | 1 |
| 17A | 27391 | Spring for Condenser Frame (C-279) | 1 |
| 18 | 27018 | Latch, for condenser frame (A1 11 702 20) | 2 |
| 19 | 27324 | Cab Fan W/Blower (73R9202) | 1 |
| 20 | 27676 | Blower Motor | 1 |
| 21 | 27146 | #8 Hose- compressor disc. to condenser 75--- | 1 |
| 22 | 27865 | #6 Hose- condenser to dryer 137--- | 1 |
| 22 | 27147 | #6 Hose- condenser to dryer 74-136 | 1 |
| 23 | 27148 | #6 Hose- dryer to cab 74--- | 1 |
| 24 | 27149 | #6 Hose- cab wall to expansion valve 74--- | 1 |
| 25 | 27150 | #10 Hoses- expansion valve to cab wall 74--- | 1 |
| 26 | 27866 | #10 Hose- compressor suction to cab 137--- | 1 |
| 26 | 27151 | #10 Hose- compressor suction to cab 74-136 | 1 |
| 27 | 27323 | Compressor Mounting Bracket (5150-1) 137 - 436 | 1 |
| 28 | 27894 | AC Belt Tension Arm 137 - 436 | 1 |
| 29 | 27893 | AC Belt Tension Pulley 137 - 436 | 1 |
| 30 | 27323 | Compressor Mounting Bracket (5150-1) 1 - 136 | 1 |
| 31 | 27472 | Compressor Take-Up Weldment 1 - 136 | 1 |
| 32 | 26878 | Take-up Bolt 4-1/2” 1 - 136 | 1 |
| 33 | 26876 | AC Tension Block 1 - 136 | 1 |
| 34 | 28812 | Air Conditioner Belt #XL9420 437--- | 1 |
| 35 | “O” Rings for AC - #6, #8, #10 Required | ||
| 36 | 27949 | 134A Freon | 1 |
| 40 | JD6107 Temperature Control (72R7000) | 1 | |
| 41 | JD6105A Hot Water Valve | 1 |
