← Jackrabbit JR 400-180 (s/n 823-1230)
Engine Components · Jackrabbit Jackrabbit JR 400-180 (s/n 823-1230)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| K1 | 22414 | Vertical Socket | |
| K2 | 28401 | A/C Pulley Bearing | |
| K3 | 27894 | A/C Pulley Kit | |
| K4 | 27893 | A/C Pulley | |
| K5 | 28812 | A/C Belt T3 | |
| K6 | 27239 | Air Filter | |
| K7 | 27237 | Air Filter Primary | |
| K8 | 27238 | Air Filter Secondary |
