← Jackrabbit JR 400-180 (s/n 823-1230)
Hydraulics · Jackrabbit Jackrabbit JR 400-180 (s/n 823-1230)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| J17 | 23548A | Hydraulic Filter | |
| J18 | 29751 | Steering Cylinder | |
| J19 | 29752 | Steering Kit Cylinder Seal Kit | |
| J20 | 28316 | Steering Column | |
| J21 | 22026B | Steering Column Nut | |
| J22 | 22026A | Steering Motor Seal Kit | |
| J23 | 22026 | Steering Motor Dan Foss | |
| J24 | 22126 | Auger Motor | |
| J27 | 33122 | Walvoil Valve | |
| J28 | 28306 | Sight Gauge Lsp-151-05-01 | |
| K34 | 28961 | Serpentine Belt | |
| M1 | 26449 | Front Leaf Spring |
