← Jackrabbit 30-36 Elevator (CAT 3.4L)
30800 30/36 1 Note: · Jackrabbit Jackrabbit 30-36 Elevator (CAT 3.4L)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| D-1 | 24537 | JACLRABBIT (White) | 1 |
| D-2 | 24538 | JACKRABBIT (Brown) | 2 |
| D-3 | 24546 | DIESEL (White) | 1 |
| D-4 | 24548 | HYDRAULIC (White) | 1 |
| D-5 | 24548A | HYDRAULIC (Brown) | 1 |
| D-6 | 24986 | CONTROL PANEL | 1 |
| D-7 | 27583 | WARNING (DECAL) | 2 |
| M-1 | 28834 | Axel Assembly | 2 |
| M-2 | 27020 | Tires 12-16.5 TL R-3 | 2 |
| M-3 | 28917 | Rims 16.5 x 9.75 | 1 |
| M-4 | 24751 | Fuel Cap #703-1060 | 1 |
| M-5 | 27285 | Gas Shock | 1 |
| P-1 | 25750 | Beige Touch Up | 1 |
| P-2 | 25750A | Brown Touch Up | 1 |
| P-3 | 27552 | Primer, mixed | 1 |
| P-4 | 27552-1 Primer, 1 gal. | 1 | |
| P-5 | 27552-2 Activator 1 gal. | 1 | |
| P-6 | 27552-A Beige, mixed 1 gal. | 1 | |
| P-7 | 27552-AA Beige, not mixed 3/4 gal. | 1 | |
| P-8 | 27552-B Brown, mixed 1 gal. | 1 | |
| P-9 | 27552-BB Brown, not mixed ¾ gal | 1 | |
| P-10 | 27552-C Hardener 1 pt. | 1 | |
| P-11 | 27552D | Enhancer, pt. | 1 |
