← Jackrabbit 30-36 Elevator (CAT 3.4L)
Isometric View · Jackrabbit Jackrabbit 30-36 Elevator (CAT 3.4L)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| W-22 | 29346 | 24" Cross Conveyor Belt With Cleats | 1 |
| W-23 | 29443 | 24” Rubberized Idler Pulley | 1 |
| W-24 | 29453 | Cross Conveyor Seal | 1 |
| W-25 | 29462 | 24" Cross Conveyor Belt | 1 |
| W-26 | 29357 | Conveyor Motor | 1 |
| B-14 | 26493 | 1" Motor Coupling | 1 |
| B-1 | 26464B | 3/8" - Bearing Puller | 2 |
| B-2 | 26464D | 3/8" - Bearing Pusher | 2 |
| W-12 | 27523C | 24" Lacing Pin (NOT SHOWN) | 1 |
| W-20 | 22977 | Bearing (1” Pillow Block) | 4 |
| W-24 | W-25 | ||
| W-22 | B-2 |
