← Jackrabbit 30-36 Elevator (CAT 3.4L)
With Operator'S Manual · Jackrabbit Jackrabbit 30-36 Elevator (CAT 3.4L)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| N-1 | 26034 | Incline Conveyor Motor | 1 |
| N-2 | 25996 | Upper Torque Arm | 1 |
| N-3 | 27352 | Clamping Collar | 1 |
| N-4 | 29502 | Coupler 1-1/2" I.D. | 1 |
| N-5 | 22097 | Bearing (1-1/2" Pillow Block) | 2 |
| N-6 | 28441 | Upper Drive Pulley 36" With LG & Shaft | 1 |
| N-7 | 28440 | Snub Roller 36" Length | 1 |
| N-8 | 23524 | Flangette Bearing For Snub Roller | 2 |
| N-9 | 28892 | 36" X 70'-3" Giant Z Incline Belt | 1 |
| N-10 | 28506 | Iddler Roller 36-3/8" Length Return Roller | 6 |
| N-4 | N-1 | ||
| N-9 | N-5 | ||
| N-11 | 27307 | Bearing Housing For Return Rollers (End Caps) | 14 |
| N-12 | 27306 | Bearings For Return Rollers | 14 |
| N-13 | Shaft & #21 Spring For 36-3/8" Return Roller | 7 | |
| N-14 | 28936 | Belt Wipers (UHMW) 36" Incline Belt | 2 |
| N-15 | 22096 | Bearing (1-1/4" Pillow Block) | 2 |
| N-16 | 31067 | Position Bearing For Incline Conveyor | 2 |
| N-17 | 28418B | 36" Idler Pulley | 1 |
| N-14 | N-13 H-1 N-16 N-15 N-17 | ||
| B-1 | 26464B | 3/8" - BEARING PULLER | 2 |
| B-2 | 26464D | 3/8" - BEARING PUSHER | 2 |
| B-3 | 26887 | Belt Wiper UHMW 37” | 1 |
| B-4 | 28891 | (30” x 309”) Giant Z Bin Belt | 1 |
| B-5 | 26018 | Idler Roller 30-3/8” (Return Roller) | 2 |
| B-6 | 27307 | Bearing Housing (End Cap) | 4 |
| B-7 | 27306 | Bearing (For Return Rollers) | 4 |
| B-8 | 28216 | Hex Shaft For Return Rollers 32-3/8” | 2 |
| B-9 | 29946 | Transition Seal – (LH) | 1 |
| B-10 | 29947 | Transition Seal – (RH) (Not Shown) | 1 |
| B-11 | 28934 | Transition Seal UHMW | 2 |
| B-12 | 29104 | Lower HYD. Motor (Not Shown) | 2 |
| B-13 | 29806 | Seal Kit Motor for (RS180201) (Not Shown) | 1 |
| B-14 | 26493 | Motor Coupler (Not Shown) | 2 |
| B-15 | 28935 | Lower Torque Arm (Not Shown) | 2 |
| B-16 | 28832A | 30” Drive Pulley With Lag | 2 |
| B-8 | B-3 B-4 N-15 B-1 B-16 B-9 | ||
| B-16 | N-15 | ||
| C-1 | 33885 | Radiator Cap – 16PSI. | |
| C-2 | 33886 | Alternator | |
| C-3 | 33887 | Starting Motor AS | |
| C-4 | 33891 | Belt - Serpentine | |
| C-5 | 33892 | Fan - Six Blade | |
| C-6 | 33894 | Switch - Oil Pressure | |
| C-7 | 33896 | Thermostat | |
| C-8 | 33900 | Filter Element - Fuel - Primary | |
| C-9 | 33901 | Filter As - Oil Engine Oil | |
| C-10 | 33902 | Filter GP - Fuel - Secondary | |
| C-11 | 33903 | Kit - Drain Fuel Filter | |
| C-7 | C-2 C-5 C-3 C-3 C-2 C-7 C-4 C-8 C-5 C-10 C-11 C-6 C-9 C-8 | ||
| C-12 | 33888 | Sensor - Liquid Level Fuel Water Separator | |
| C-13 | 33889 | Sensor - Temperature Fuel And Ambient Air Temp | |
| C-14 | 33890 | Plug - Glow | |
| C-15 | 33893 | Sensor - Speed Primary Timing | |
| C-16 | 33895 | Sensor Air | |
| C-17 | 32520 | Sensor-Temperature | |
| C-18 | 33897 | Glow Plug | |
| C-19 | 32521 | Sensor - Temperature | |
| C-20 | 33898 | Filter Element As - Air Primary | |
| C-21 | 33899 | Filter Element As - Air Secondary | |
| W-1 | 29562 | Spreader Bar (No Flags) | 31 |
| W-2 | 29560 | Spreader Bar (6 Flags) | 15 |
| W-3 | 29559 | Spreader Bar (5 Flags) | 15 |
| W-4 | 22184 | 11 T Sprocket | 4 |
| W-5 | 27141 | CA 557 Master Link | |
| W-6 | 27142 | CA557 With A4 Attachment W-20 | |
| W-7 | 24395D | Torque Arm Weldment (WoodChuck 5.25" Arm Pin) | 1 |
| W-13 | 60808 | Woodchuck Desticker Chain 1 W-13 | |
| W-14 | 29358 | Woodchuck Chain Motor | 1 |
| W-15 | 28937 | Cylinder 1-1/2" X 6" Woodchuck Lift | 2 |
| W-16 | 26231B | Shield-Lower Sprocket (UHMW) | 2 |
| W-17 | 26232 | Shield-Lower Sprocket (Metal) | 4 |
| W-18 | 26201 | 6T 550 Eccentric Sprocket With Bearing 5/8” Bore | 4 |
| W-19 | 26198 | Eccentric Sprocket Bearings | 4 |
| W-20 | 22977 | VAK. 1" Pillow Block Bearing | 2 |
| W-21 | 22983 | 8T 550 Idler - 5/8" Bore G&G 6 SEE UHMW ON PAGE | 10 |
| W-14 | W-7 | ||
| 4 | W-15 |
