← Jackrabbit 30-36 Elevator (Deutz)
Woodchuck · Jackrabbit Jackrabbit 30-36 Elevator (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 500 | 28510 | Valves SD 5/3A | 1 |
| 501 | 28240 | Front Spindle Plate Assembly | 1 |
| 502 | 28238 | Steering Cylinder Assembly | 1 |
| 502A | 28317 | UHMW Internal Spacer for slide tube (1/2” x 3 7/8” x 25 7/8”) | 4 |
| 503 | 27354 | Cylinder CTRE | 1 |
