Bin Conveyor Section Cont. · Jackrabbit Jackrabbit 30-36 Elevator (Deutz)
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 100 | 27014 | Air Filter Inner (Don. P829332) | 1 |
| 101 | 27013 | Air Filter-Outer (Don. P827653) | 1 |
| 101A | 27015 | Air Filter Assembly G0700018 | 1 |
| 101B | 27015A | Air Filter Mounting Band P777731 | 1 |
| 101C | 27015B | Air Filter Vacuator P158914 | 1 |
| 102 | 27013A | End Cover (P636202) | 1 |
| 103 | 28795 | Restriction Indicator ( 4235036) | 1 |
| 104 | 27011 | Fuel Filter (Deutz 117-4696) | 1 |
| 104A | 27943 | Fuel Strainer in line 117-8753 | 1 |
| 105 | 27010 | Oil Filter (Deutz 117-4416) | 1 |
| 105A | 28158 | Dip Stick (427-2816) | 1 |
| 106 | 27168B | Fan Belt (Deutz 117-9564) | 1 |
| 107 | 27202D | Fuel Shut off Solenoid (428-7583) | 1 |
| 107A | 27202C | Wiring Loom for Fuel Shut Off Solenoid | 1 |
| 109 | 27203C | Fuel Pump (428-6113), F4L2011 | 1 |
| 109A | 27203B | O-Ring (117-9160) | 1 |
| 110 | 28481 | Fuel Injector Return Line Kit 428-1428 | 1 |
| 115 | 27656 | Throttle Solenoid (1756E) | 1 |
| 115A | 27654 | Solenoid Rubber Boot | 1 |
| 116 | 27655 | Trombete Module (P515 A57 12V) | 1 |
| 116 | 27657 | Coil Commander (SA4687) | 1 |
| 117 | 27310 | Throttle Linkage Kit, Assembly | 1 |
| 118 | 27776 | Throttle Lever 417- 9754 | 1 |
| 118A | 28484 | Throttle Lever | 1 |
| 124 | 28346 | SYN. Throttle Solenoid (2370ES-12E 2ul B5) | 1 |
| 124A | Solenoid Rubber Boot | 1 | |
| 124B | 27657 | SYN. Coil (SA467 176) | 1 |
| 125 | 28349 | Yoke (175 403 002-5/16-24 90deg. QD & Short) | 1 |
| 126 | 28351 | Throttle Arm | 1 |
| 127 | 28352 | Female Yoke End | 1 |
| 128 | 2-252 O Ring | 2 | |
| 129 | 28392 | Compression Spring | 1 |
| 130 | 27803 | Alternator Rebuilt Deutz | 1 |
| 131 | Starter 118 3599 | 1 | |
| 137 | 25026A | Exhaust Pipe | 1 |
| 137A | 25026 | Exhaust Pipe | |
| 138 | 27285 | Gas Shock for Engine Door | 1 |
| 139 | 27959 | Rubber Ring Isolator Deutz Engine | 1 |
| 142 | 22424 | Hour Meter (85002-03) | 1 |
| 155 | 27131A | Engine Oil Temperature Gauge (118 2577) 2” hole | 1 |
| 155A | 28486 | Engine Oil Temperature Sender (118 2876) | 1 |
| 155B | 28485 | Oil Pressure Sender (117 5881) | 1 |
