← Jackrabbit 20/30 JJ Elevator
Jjl 20/30 Elevator · Jackrabbit Jackrabbit 20/30 JJ Elevator
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 100 | 27014 | Air Filter Inner (Don. P829332) 116--- | 1 |
| 100 | 26774 | Air Filter Safety Element (118-0869) 100-115 OBS | |
| 101 | 27013 | Air Filter-Outer (Don. P827653) 116--- | 1 |
| 101A | 27015 | Air Filter Assemble G0700018 116--- | 1 |
| 101B | 27015A | Air Filter Mounting Band P777731 116--- | 1 |
| 101C | 27015B | Air Filter Vacuator P158914 116--- | 1 |
| 101D | 28795 | Restriction Indicator (Deutz) 162--- | 1 |
| 101 | 26773 | Air Filter Primary (131-9142) 100-115 OBS | |
| 101 | 27117 | Air Filter (438 4102) 1-99 | 1 |
| 102 | 27013A | End Cover (P636202) 116--- | 1 |
| 103 | 27531 | Conversion Kit To Donaldson Filters 1-115 | 1 |
| 104 | 27011 | Fuel Filter (Duetz 117-4696), L1101 &2011 1--- | 1 |
| 104A | 27943 | Fuel Strainer in line 117-8753 | 1 |
| 105 | 27010 | Oil Filter (Duetz 117-4416), F2L1101 &2011 1--- | 1 |
| 106 | 27168A | Fan Belt (Duetz 117-9566), F2L2011 207--- | 1 |
| 107 | 27202B | Fuel Shut Off Solenoid 427-2956), L2011 207--- | 1 |
| 107A | 27351A | Wiring Loom For Fuel Shut Off Solenoid (F2L2011) 207--- | 1 |
| 107B | 27351 | Wiring Loom For Fuel Shut Off Solenoid 1-206 | 1 |
| 109 | 27203C | Fuel Pump (428-6113), F2L,F3L,F4L2011 207--- | 1 |
| 110 | 27492 | Fuel Injector Return Line Kit 0417-8631 1--- | 1 |
| 112 | 24744 | Throttle Solenoid W/Module 1-175--- | 1 |
| 113 | 24744A | Throttle Solenoid 1-175--- | 1 |
| 113A | 27654 | Solenoid Rubber Boot | 1 |
| 114 | 24744B | Trombete Module 1-175--- | 1 |
| 115 | 27656 | Throttle Solenoid (1756E) 176--- | 1 |
| 115A | Solenoid Rubber Boot | 1 | |
| 116 | 27655 | Trombete Module (P515 A57 12V) 176--- | 1 |
| 116 | 27657 | Coil Commander (SA4667) 176--- | 1 |
| 117 | 27310 | Throttle Linkage Kit, assembly | 1 |
| 118 | 27776 | Throttle Lever 417- 9754 for Duetz 1011 | 1 |
| 120 | 27803 | Alternator Rebuilt Duetz | 1 |
| 137 | 25026 | Exhaust Pipe | 1 |
| 138 | 27285 | Gas Shock for Engine Door | 1 |
| 139 | 27959 | Rubber Ring Isolator Duetz Engine | 1 |
| 140 | 27407 | Oil Cooler For 3 Cylinder Engine | 1 |
| 141 | 27876A | Oil Pressure Sender (CH86281) three prong 207--- | 1 |
| 142 | 22424 | Hour Meter (85002-03) 109--- | 1 |
| 142B | 27762A | Drive Plate Kit, (Drive & Bell Housing Cover) 123296, 123076 | |
| 145 | F2L2001 Engine 2 Cylinder Engine, | 1 | |
| 145A | 27762 | Drive Plate Kit, (Drive & Bell Housing Cover) 123 | 655 |
| 155 | 27131A | Engine Oil Temperature Gauge (118 2577) 2” hole | 1 |
