Jjl 20/20 Elevator · Jackrabbit Jackrabbit 20/20 JJ Elevator

Tap a circled number on the diagram to identify the part.

#	Part number	Description	Qty
5	22097	Bearing (1-1/2” Pillow Block)	2
8	23524	Flangette Bearing (#52 MST 22PPRAG)	2
9	27376	(20” x 64’ 4”) Giant Z Incline Belt 1-129 & 207---	1
10	27306	Bearings For Return Rollers	16
16	22977	Bearing (1” Pillow Block)	6
26	31067	Bearing (FC350 1-1/2”)	2
30	26464	Bearings Pad	8
33	27377	(20” x 317”) Giant Z Bin Belt 115---	1
300	24537	JACLRABBIT (White)	1
350	23944	Tires 7.5 X 16 LTE	2
500	28510	Valves	1
501	28240	Front Spindle Plate Assembly	1
502	28238	Steering Cylinder Assembly	1
502A	28317	UHMW Internal Spacer for slide tube (1/2” x 3 7/8” x 25 7/8”)	4
503	27354	Cylinder CTRE	1
