Figure 6 · Flory Flory 9685/9610 Tractor Sweeper
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | FLCT2111 | BEARING | 2 |
| 2 | TM6245 | YOKE | 1 |
| 3 | 3/4JN-C | NUT | 1 |
| 4 | TM1234 | BOLT-axle | 1 |
| 5 | 4315 | SPACER | 2 |
| 6 | 4247 | SEAL | 2 |
| 7 | LM11949 | CONE-bearing | 2 |
| 8 | LM11910 | CUP-bearing | 2 |
| 9 | FS-14014 | WHEEL | 1 |
| 10 | 18X8508 | TIRE | 1 |
| 11 | TM1018 | COLLAR-shaft | 1 |
| 12 | T9000 | KIT-bearing (includes items 5-8) | 1 |
