Figure 4 · Flory Flory 78 Series Sweeper
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | S208C | SWITCH, toggle | 2 |
| 2 | S2098 | SWITCH, toggle | 1 |
| 3 | ME3012 | BLOCK, fuse | 1 |
| 4 | ME1777 | COIL, reel valve | 1 |
| 5 | ME1877 | COIL, float valve | 1 |
| 6A | VL5090 | VALVE, directional control | 2 |
| 6B | ME1260 | COIL, valve | 2 |
| 7 | ME3990 | BLOCK, terminal (90 SERIES ONLY) | 1 |
| 7 | S12SC001 | MODEL SIDE KICK |
