Figure 3 · Flory Flory 78 Series Sweeper
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | T69257 | MOUNT, curtain (mfg.# 986~ ) | 1 |
| 2 | T69977 | CLAMPSTRIP, top/side curtain | 2 |
| 3 | T39077 | CURTAIN, rubber | 1 |
| 4 | T69277 | I-FRAME | 1 |
| 5A | HC2522 | CYLINDER, folding | 1 |
| 5B | 1C4433 | SEAL KIT, cylinder | 1 |
| 6 | T69377 | T-FRAME | 1 |
| 7 | T29197 | TOP, support frame | 1 |
| 8 | T29137 | HINGE, support frame | 1 |
| 9 | T69477 | FRAME, support | 1 |
| 10 | T67007 | MOUNT, battery | 1 |
| 11 | C27-XHD | BATTERY | 1 |
| 12 | CV0085 | BOX, battery | 1 |
| 13 | T69077 | L-FRAME | 1 |
| 14A | HC2518 | CYLINDER, lift | 1 |
| 14B | 1C4433 | SEAL KIT, cylinder | 1 |
| 15 | CA6012-2T | CLAMP, hose block | 1 |
| 15 | SKPB003 | MODEL SIDE KICK |
