Figure 2 · Flory Flory 78 Series Sweeper
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | T29347 | COVER, paddle wheel | 1 |
| 2 | F61758 | WHEEL, paddle | 1 |
| 3 | T3041 | PADDLE, wire end | 10 |
| 4 | T6114 | CLAMPSTRIP, paddle | 10 |
| 5 | T59077 | SHAFT, endplate | 1 |
| 6 | PBC2100 | BEARING, pillow block | 2 |
| 7 | 1610100 | BUSHING | 2 |
| 8 | T69547 | HUB, endplate | 1 |
| 9 | SE2689 | COVER, reel bearing (rear) | 8 |
| 10 | BR0690 | BEARING, tine bar (bearing only) | 8 |
| 11 | BR1690 | BEARING, tine bar (housing & bearing) | 8 |
| 12 | CV0690 | COVER, reel bearing (front) | 8 |
| 13 | T69507 | ENDPLATE, reel (4 bar) | 2 |
| 13 | T61505 | ENDPLATE, reel (5 bar) | 2 |
| 14 | T69527 | PLATE, support | 2 |
| 15A | HM1152 | MOTOR, reel | 1 |
| 15B | HM1152-K | SEAL KIT, motor | 1 |
| 15C | SF3152 | SHAFT, motor | 1 |
| 16 | 23399 | HUB, reel drive | 1 |
| 17 | T69797 | TINE BAR (mfg#. 840~) | 4 |
| 17 | TK6079 | TINE BAR (mfg#. ~824) | 5 |
| 18 | T39197 | TINE, wire (mfg#. 840~) | 4 |
| 18 | TK3019 | TINE, wire (mfg#. ~824) | 5 |
| 19 | T69927 | RISER, tine bar (mfg#. 840~) | 4 |
| 19 | T69917 | RISER, tine bar (mfg#. ~824) | 5 |
| 20 | TK3032 | SWEEP (mfg#. ~824) | 5 |
| 21 | T69487 | CLAMPSTRIP, sweep (mfg#. ~824) | 5 |
| 21 | SKPB002 | MODEL SIDE KICK |
