Figure 3 · Flory Flory 33 Series Sweeper
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1A | HM1152 | MOTOR, reel | 1 |
| 1B | HM1152-K | SEAL KIT, motor | 1 |
| 1C | SF3152 | SHAFT, motor | 1 |
| 2 | 23399 | HUB, reel drive | 1 |
| 3 | T69507 | ENDPLATE, reel | 2 |
| 4 | T69527 | PLATE, support | 2 |
| 5 | SE2689 | COVER, reel bearing (rear) | 8 |
| 6 | BR0690 | BEARING, tine bar (bearing only) | 8 |
| 7 | BR1690 | BEARING, tine bar (housing & bearing) | 8 |
| 8 | CV0690 | COVER, reel bearing (front) | 8 |
| 9 | T59077 | SHAFT, endplate | 1 |
| 10 | PBC2100 | BEARING, pillow block | 2 |
| 11 | 1610100 | BUSHING | 2 |
| 12 | T6114 | CLAMPSTRIP, paddle | 10 |
| 13 | T3041 | PADDLE, wire end | 10 |
| 14 | T29343 | COVER, paddle wheel | 1 |
| 15 | F61758 | WHEEL, paddle | 1 |
| 16 | T69547 | HUB, endplate | 1 |
| 17 | T69927 | RISER, tine bar | 4 |
| 18 | T39197 | TINE, wire | 4 |
| 19 | T69797 | TINE BAR | 4 |
| 19 | 3SPB002 | MODEL 33 SERIES SIDE KICK |
