Figure 71 · Flory Flory 33 Series Sweeper
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| COMPONENTS | (OPTIONAL 4WD) | ||
| 21 | VL5030 | VALVE, traction | 1 |
| 22A | HM1154 | MOTOR, wheel (front) | 2 |
| 22B | HM6242-K | SEAL KIT, motor | 2 |
| 23A | HM7183-2 | MOTOR, wheel (right rear) | 1 |
| 23B | HM6183-K | SEAL KIT, motor (includes SS4601) | 1 |
| 23C | SS4601 | SEAL, input shaft | 1 |
| 24A | HM7183-2 | MOTOR, wheel (left rear) | 1 |
| 24B | HM6183-K | SEAL KIT, motor (includes SS4601) | 1 |
| 24C | SS4601 | SEAL, input shaft | 1 |
| 24C | HOSE | LIST (OPTIONAL 4WD) | |
| 90 | HOSE, hydrostat port 'A' to traction valve port 'A' | 1 | |
| 91 | HOSE, traction valve port 'M2' to front right B/H Tee | 1 | |
| 92 | HOSE, front left B/H tee to hydrostat port 'B' tee | 1 | |
| 93 | HOSE, left B/H tee to left front motor port 'A' | 1 | |
| 94 | HOSE, left B/H tee to right front motor port 'B' | 1 | |
| 95 | HOSE, right B/H tee to left front motor port 'B' | 1 | |
| 96 | HOSE, right B/H tee to right front motor port 'A' | 1 | |
| 97 | HOSE, lower B/H tee to left front motor case port | 1 | |
| 98 | HOSE, lower B/H tee to right front motor case port | 1 | |
| 99 | HOSE, traction valve port 'M1' tee to left rear motor port 'B' | 1 | |
| 100 | HOSE, traction valve port 'M1' tee to right rear motor port 'A' | 1 | |
| 101 | HOSE, lower B/H tee to tank bottom middle port tee | 1 | |
| 102 | HOSE, traction valve port 'T' to tak bottom middle port tee | 1 | |
| 102 | 33HYD001 | MODEL 33 SERIES SWEEPER |
