Figure 2 · Flory Flory Blower 2500
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | TB2135 | SHIELD | 1 |
| 2 | TB6720 | TANK-oil | 1 |
| 3 | SP113B | FILLER (with cap) | 1 |
| 4 | LX0510 | GAUGE-oil | 1 |
| 5A | F11BA | FILTER & BASE ASSEMBLY | 1 |
| 5B | FL110 | FILTER | 1 |
| 6 | 12623 | PIN-linch | 3 |
| 7 | 12427 | PIN-top link (s/n ~488) | 1 |
| 7 | 12693 | PIN-top link (s/n 489~) | 1 |
| 8 | TB5266 | SHAFT-fan | 1 |
| 9 | PBC2110 | BEARING | 2 |
| 10 | 1432A | PIN-lift (s/n ~488) | 2 |
| 10 | 12695 | PIN-lift (s/n 489~) | 2 |
| 11 | TB6740 | PLATE-pump mounting | 1 |
| 12 | TB2130 | SHIELD | 1 |
| 13 | TB2132 | SHIELD | 1 |
| 14A | CP148R | PUMP | 1 |
| 14B | CPK084 | KIT-seal | 1 |
| 15A | 4016402 | CHAIN (not shown) | 1 |
| 15B | 40DCL | LINK-connecting (not shown) | 1 |
| 15C | 4016011 | COUPLER-pump | 1 |
| 15D | 4016100 | COUPLER-fan shaft | 1 |
| 16 | TB6002 | BRACKET-rear oil tank support (not shown) | 1 |
| 16 | TB6003 | BRACKET-front oil tank support (not shown) | 1 |
| 17 | TB6618 | FRAME-housing (not shown) | 1 |
