Auger & Auto Unload Schematic · Flory Flory 1190-C Cart
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1A | HM1189 | MOTOR, auger drive (s/n ~1089 and 1135~) | 2 |
| 1A | EM179 | MOTOR, auger drive (s/n 1090 -1134) | 2 |
| 1B | HM2149-K | SEAL KIT, motor (s/n ~1089 and 1135~) | 2 |
| 1B | CM226SK | SEAL KIT, motor (s/n 1090 - 1134) | 2 |
| 2A | RDRS197530 | VALVE, flow control | 1 |
| 2B | MK2189 | SEAL KIT flow control valve | 1 |
| 3A | HM1192 | MOTOR, conveyor drive | 1 |
| 3B | HM2061-K | SEAL KIT, motor | 1 |
| 4 | VL6010 | VALVE, check | 1 |
| 5 | SD4BA | VALVE, auto unload | 1 |
| 5 | 20A | HOSE, quick couplers to adapter plate 60" | 2 |
| 20B | 6601-12-12 | COUPLER, quick (female) | 2 |
| 20B | 6602-12-12 | COUPLER, quick (male) | 2 |
| 21 | HOSE, adapter plate to steel lines 25" | 2 | |
| 25 | HOSE, flow contr. 'CF' to right auger motor 'RIGHT' 43” | 1 | |
| 26 | HOSE, rt. auger mtr 'RIGHT' to lt. auger mtr 'RIGHT' 28” | 1 | |
| 27 | HOSE, left auger motor 'LEFT' to flow control 'EX' 75" | 1 | |
| 29 | HOSE, bott. steel line to unload valve 'C' bott. of tee 56” | 1 | |
| 30 | HOSE, unld. valve 'C' top of tee to chk. valve at 'E' 38” | 1 | |
| 31 | HOSE, tee leg on chk. valve 'A' to conv. motor front 48” | 1 | |
| 32 | HOSE, conv. mtr. rear to 90 deg. elbow at unld. valve'E' 51” | 1 | |
| 33 | HOSE, front of tee at unload valve 'A' to 'F' port 46" | 1 | |
| 34 | HOSE, unload valve 'D' port to tee on top steel line 61" | 1 | |
| 35 | HOSE, unload valve 'B' port to flow control 'IN' 31" | 1 | |
| 36 | HOSE, flow contr. 'EX' tee bott. to top steel line chk. valve 21" | 1 | |
| 36 | 1190PB010 | MODEL 1190-C CART |
