Conveyor Chains · Flory Flory 1190-C Cart
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | C60041 | CARCASS, chain (almond) | 1 |
| 2 | C60141 | CARCASS, chain (pecan) | 1 |
| 3 | C60241 | CARCASS, chain (walnut) | 1 |
| 4 | C6006 | FLITE, chain | 66 |
| 5 | C40761 | WIRE CHAIN, blank (almond) | 1 |
| 6 | C40781 | WIRE CHAIN, blank (pecan) | 1 |
| 7 | C40701 | WIRE CHAIN, blank (walnut) | 1 |
| 8 | C1163 | WIRE, chain lacing (almond) | 1 |
| 9 | C1165 | WIRE, chain lacing (pecan) | 1 |
| 10 | C1167 | WIRE, chain lacing (walnut) | 1 |
| 11 | C6516 | STRAP, chain (5 bolt)(almond) | |
| 12 | C6416 | STRAP, chain (4 bolt)(almond & pecan) | |
| 13 | C6417 | STRAP, chain (4 bolt)(walnut) | |
| 14 | CH5557 | LINK, connecting link (w/ tab) | |
| 15 | CH5557-2 | LINK, connecting link (w/o tab) | |
| 16 | CH6557 | LINK, connecting half | |
| 17 | C40751 | WIRE CHAIN, complete (almond) | 1 |
| 18 | C40771 | WIRE CHAIN, complete (pecan) | 1 |
| 19 | C40791 | WIRE CHAIN, complete (walnut) | 1 |
| 19 | 1190PB005 | MODEL 1190-C CART |
