LIGHT KIT OPTION - PART NUMBER 899-0268 (SHEET 3 OF 3) · Weiss McNair 9800 Harvester
Tap a circled number on the diagram to identify the part.
✕
| # | Part number | Description | Qty |
|---|---|---|---|
| 1 | 890-160 | SIDE SHOE BRKT, RH 1 EA | |
| 2 | 890-161 | SIDE SHOE BRKT, LH 1 EA | |
| 3 | 899-0012 | SIDE SHOE BAR 2 EA | |
| 4 | 948-136 | SIDE SHOE RUBBER 2 EA | |
| 5 | 23010-01 | 1/4 - 20 NYLOCK 4 EA | |
| 6 | 26003-01 | WASHER 1/4 " FLAT PLATED 8 EA | |
| 7 | 26009-01 | 1/2-13 NC NUT 8 EA | |
| 8 | 27089-01 | WASHER 1/2" FLAT PLATED 8 EA | |
| 9 | 27091-01 | 1/2 LOCK WASHER 8 EA | |
| 10 | 27127-01 | CAPSCREW 1/4 X 1-1/4 NC #8 4 EA | |
| 11 | 27143-05 | CARRIAGE BOLT, 1/2-13 X 3" 2 EA |
